Veolia E-Cell MK-3 Mini HT EDI module for pharmaceutical ultrapure water production
Detalhes do produto:
| Lugar de origem: | CHINA |
| Marca: | VEOLIA |
| Certificação: | CE |
| Número do modelo: | Veolia edi mk-3miniht |
| Documento: | FSpwE-CellMK-3MiniHT_EN.pdf |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 1 pc |
|---|---|
| Preço: | negociável |
| Detalhes da embalagem: | Embalagem de exportação padrão |
| Tempo de entrega: | 1 mês |
| Termos de pagamento: | T/T. |
| Habilidade da fonte: | 60000 unidades por mês |
|
Informação detalhada |
|||
| Faixa de taxa de fluxo miniht: | 0,5-1,6 m3 /h (2,2–7,0 gpm) | Miniht peso de envio de produto: | 57 kg (126 libras) |
|---|---|---|---|
| Miniht dimensões deste modelo (largura x altura x profundidade): | 30 cm x 61 cm x 29 cm | Miniht Resistividade: | ≥ 10 (farmacêutico) ou ≥ 16 mohm-cm (industrial |
| Produto sódio: | ≤ 3 ppb (industrial) | Temperatura máxima de higienização do produto: | 85ºC (185ºF) |
| Produto máximo de hanitização da pressão: | 2,1 bar (30 psi) | aplicação do produto: | Comparação de água purificada farmacêutica e laboratorial com USP e EP |
| Destacar: | Veolia E-Cell MK-3 EDI module,pharmaceutical ultrapure water EDI,mini HT EDI module |
||
Descrição de produto
The Veolia E-Cell MK-3 Mini HT Electrodeionization (EDI) Module is designed for polishing reverse osmosis (RO) permeate to produce ultra-pure water. It delivers high-purity water (up to 10 MΩ·cm resistivity, with ≤5 ppb silica) without chemical regeneration. Ideal for power generation, semiconductors, microelectronics, and pharmaceuticals, this compact module (30x61x28 cm) offers continuous operation, high recovery rates (78-93%), and hot water sanitization capabilities
| Flow Rate Range | 0.5–1.6 m³/h (2.2–7.0 gpm) |
| Shipping Weight | 57 kg (126 lbs) |
| Dimensions | 30 cm x 61 cm x 29 cm |
| Resistivity | ≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial) |
| Maximum Sanitization Temperature | 85ºC (185ºF) |
- Patented HT-EDI™ technology for reagent-grade water production
- 90% lower energy consumption compared to mixed-bed systems
- Maintenance-free operation with intelligent control system
- Real-time monitoring of conductivity, pH, and pressure drop
- Patented staggered flow channel design prevents scaling
Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.
- Basic Unit - Standalone purification
- RO-EDI Integrated - Complete purification skid
- GMP Version - With full validation support
- CE, RoHS, CSA and EAC marked
- FDA-compliant materials
- UKCA certified
- Manufactured in ISO 9001 and ISO 14001 facility
- Halal certified by IFANCA®
| Parameter | Value |
|---|---|
| Inlet Pressure | 6.9 bar (100 psi) |
| Max Temperature | 40°C (104°F) |
| Pressure Drop | 1.4-2.8 bar (20-40 psi) |
| Recovery Rate | Up to 93% |
| Conductivity | <117 µS/cm |
| pH Range | 4-11 |
Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.
