Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
Detalhes do produto:
| Lugar de origem: | China |
| Marca: | DOW |
| Certificação: | CE |
| Número do modelo: | IntegraTecTM XP 51/ XP 51 IG ((anteriormente SFD/SFP-2860XP) |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 1 unidade |
|---|---|
| Preço: | negociável |
| Detalhes da embalagem: | Embalagem padrão de exportação |
| Tempo de entrega: | 5-8 dias de trabalho |
| Habilidade da fonte: | 60000 unidades por mês |
|
Informação detalhada |
|||
| Modo de filtragem XP 51 IG: | Pressurizado externo | Tipo de membrana XP 51 IG: | Fibra oca |
|---|---|---|---|
| XP 51 IG Material de membrana: | PVDF (fluoreto de polivinilidina) | XP 51 Tamanho do poro da membrana Ig: | Aprox. 0,03 µm |
| Processo de operação do módulo: | Sem saída | Outros componentes do módulo molhado: | Poliuretano, polietileno e poliamida |
| Área de membrana ativa Ig 51 Ig: | 51 m² | XP 51 Ig Shipping Weight: | 60 kg |
| XP 51 IG Peso Vazio: | 48 kg | Peso preenchido: | 83 kg |
| Aplicação do produto: | Tratamento de águas residuais | Vantagens do XP 51 IG: | adequado para projetos de sistema com altura ou espaço limitado |
Descrição de produto
Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
The XP 51 is a compact model in the XP series, suitable for systems with limited height or space.
1. Membrane material: PVDF
2. Nominal pore size: approximately 0.03 μm
3. Effective membrane area per module: approximately 51 m²
4. Module diameter: approximately 203 mm (8 inches), length: approximately 1520 mm (60 inches)
5. Typical operating flux is similar to the SFP2860, typically in the range of 40–110 LMH
6. Primarily used in containerized water treatment systems, small industrial RO pretreatment units, and modular equipment.
7. This model's advantage lies in its flexible system integration, suitable for standardized export equipment and customized skids.
Key Features Proven XP™ hydrophilic PVDF fibers:
• Excellent stain and chlorine resistance.
• High removal of colloidal particles, bacteria and viruses.
• Excellent filter permeability.
• Easy to clean and wet.
Optimized module design: Open platform design to fit customer-built skids.
• Short module design for height-restricted or containerized installations.
• High operating recovery rate with high air scour tolerance.
• Reduced chemical consumption through maintenance cleaning protocols.
• Rugged materials for long service life.
• Easy installation and low maintenance costs.
Product Specifications
Operating Parameters
